FEATURES
LIGHTEST GAS CHAINSAW IN AUSTRALIA
25.0 cc professional-grade, 2-stroke engine
For outstanding performance and durability
Textured grip handles
For optimum saw control
Fine grid starter cover
Prevents debris ingestion and prolongs air filter life
Automatic, adjustable clutch-driven oiler
Operates only when the chain is moving to reduce oil consumption
Choke with automatic fast idle
Provides for easy starting
Side-access chain tensioner
For easy chain adjustments
G-Force Engine Air Pre-Cleaner™
Extends air filter life and reduces maintenance intervals
Dual-post chain brake
For increased durability
Large fuel and oil caps
Can be loosened and tightened with starter handle
SPECS
Engine displacement (cm³)
25.0
Output (kw)
1.11
Output (ps)
1.51
Dry Weight (kg)
2.3
Fuel tank capacity (l)
0.19
Chain Oil Tank Capacity (ml)
140
Fuel Consumption At Maximum Engine Power (L/h)
0.68
Priming Pump
Ignition System
CDI
Start Assist System
ES-start
Chain Brake
Inertia
Choke w/ Automatic Fast Idle Release
Chain Tensioner
Side
Saw Chain Pitch (inch)
3/8
Guide Bar Gauge (inch)
0.50
Applicable Bar Length (cm/inch)
20,25,30/8,10,12
Sound pressure level (dB(A))
99.7
Sound power level (dB(A))
110.3
CO² (g/kW・h)
961
Vibration Front handle/Rear handle (m/s²)
3.5/4.0
