FEATURES
POWER, PERFORMANCE AND PRODUCTIVITY
40.2 cc professional-grade, 2-stroke engine
For outstanding performance and durability
Heavy-duty, easy-access, automotive-style air filter
Provides superior filtration with reduced maintenance time
Starter assist system
Reduces starting effort by 30%
Automatic, adjustable clutch-driven oiler
Operates only when the chain is moving to reduce oil consumption
G-Force Engine Air Pre-Cleaner™
Extends air filter life and reduces maintenance intervals
Available in 16 in. and 18 in. bar lengths
For general trimming and limbing
SPECS
Engine displacement (cm³)
40.2
Output (kw)
1.6
Output (ps)
2.2
Dry Weight (kg)
4.6
Fuel tank capacity (l)
0.41
Chain Oil Tank Capacity (ml)
280
Fuel Consumption At Maximum Engine Power (L/h)
0.95
Priming Pump
Ignition System
CDI
Start Assist System
ES-start
Chain Brake
Inertia
Choke w/ Automatic Fast Idle Release
Chain Tensioner
Side
Saw Chain Pitch (inch)
0.325
Guide Bar Gauge (inch)
0.58 (0.050)
Applicable Bar Length (cm/inch)
38, 45 / 15, 18
Sound pressure level (dB(A))
99.2
Sound power level (dB(A))
110.0
CO² (g/kW・h)
958
Vibration Front handle/Rear handle (m/s²)
4.4 / 6.4
