Name: ISX™ 3300
Brand: Ferris
Price: 27999.0 AUD
Availability: InStock

Manufactured in United States

$27,999.00

The leader in riding comfort. Featuring next-generation suspension technology – ForeFront™ Suspension, a 61" dual-belt iCD™ cutting system, heavy-duty Hydro-Gear® ZT-5400 drive systems, and travel speeds up to 19 kmh. Enjoy smooth, fuel-saving performance over large areas with the ISX™ 3300.

TOP FEATURES

37hp Briggs & Stratton EFI-ETC Engine with Oil Guard
Dual commercial Hydro-Gear^® ZT-5400 Powertrain^® transaxles with 9" cooling fans
Arm rests, multi-position head rest, adjustable lumbar and seat recline

Features
Specs
Technical Documents
Accessories
Related Content
Reviews

FEATURES

THE LEADER IN SUSPENSION TECHNOLOGY FOR TURF

ForeFront™ Suspension System

The system utilizes four upper and lower control rods and mower-specific shocks that ensure the front caster bearing remains vertical through the full range of travel.

Ride-On Mower Warranties

Coil-Over-Shocks and all suspension-related components are covered for 5 years (60 months), for unlimited hours. We are committed to providing performance, productivity and durability.

The EFI-ETC engine with Oil Guard

The EFI-ETC engine with Oil Guard delivers a 500 hour oil change interval and 40 hp*, giving you added cutting performance to excel in thick, dense, and wet conditions. (select models)

Drive System

Dual, commercial Hydro-Gear® ZT-5400 Powertrain® transaxles with 9" cooling fans

Premium High-Back Suspension Seat

Mow in superior comfort with arm rests, multi-position head rest, adjustable lumbar and seat recline

Hercules™ II Cast-Iron

Hercules™ II Cast-Iron; 10" dia. cast-iron with industrial double row angular contact ball bearing with 1 3/16" dia. shaft. Contact ball bearings with 1 3/16" dia. shaft.

Vanguard Electronic Throttle Control

This new technology allows the engine to harness all the power that is generated for more consistent blade tip speed. (select models)

SPECS

Model

5901938

Engine

Vanguard® BIG BLOCK™ EFI with Oil Guard™ and Electronic Throttle Control

Engine Power Rating (HP) *

37

Displacement (cc)

993

PTO

Electric

Cylinders

2

Starter

Electric

Fuel Tank Capacity (L)

41.6

Cutting Width in(cm)

61 (183) Side Discharge

Cutting Height in(cm)

1.5 - 5 (38 - 127)

Spindles

Hercules™ II Cast-Iron

Deck Construction

iCD™ Cutting System, 2-Belt

Deck Discharge Type

Side Discharge

Suspension

ForeFront™ Suspension System - Front independent with four control rods paired with large size adjustable coil-over shocks and a rear swing with large adjustable coil-over shocks.

Transmission

Dual commercial Hydro-Gear® ZT-5400 Powertrain® transaxles with 9" cooling fans

Ground Speed-Fwd (kph)

0 - 19.3

Ground Speed-Rev (kph)

0 - 8.05

Dry Weight (kg)

741

Seat Package

Premium high-back suspension seat with arm rests, multi-position head rest, adjustable lumbar and back recline

Instrumentation

Dual-function hour meter, fuel level gauge in each tank

ROPS

165° foldable

Controls / Safety Group

Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls

Parking Brake / Safety Circuit

Hand operated Internal transaxle brake

Warranty (Engine) †

3-Year limited manufacturer's warranty

Warranty (Balance of Machine) †

4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Coverage on other components varies, please see operator’s manual for complete details.
