35HP Briggs & Stratton Vanguard™ V-Twin 613477-
Briggs & Stratton

35HP Briggs & Stratton Vanguard™ V-Twin 613477-

$4,845.00
/

Vanguard™ is the innovator and proven leader for Big Block™ V-Twin engine power, performance and reliability. For the most challenging applications - where downtime is not an option - the 35HP Big Block V-Twin engine has been expertly engineered to deliver the dependability hardworking people need. Our premium engine range offers a full 3-Year limited global warranty for commercial use which demonstrates our commitment to deliver the best performing products.Various exhaust systems optional.

TOP FEATURES
  • Oil Cooler Reducing oil temperature, improves lubrication and extends oil change intervals
  • Full Pressure Lubrication w/ Spin-On Oil Filter
  • Magnetron® Electronic Ignition
  • Cast Iron Sleeves
  • Low stock - 1 item left
  • Inventory on the way

FEATURES

BIG BLOCK EQUALS BIG POWER.

V-Twin OHV Technology
Superior balance, low vibration, lower emissions, improved valve life, better fuel economy and higher HP/Weight
High Efficiency Head Design
Angled ports optimizes tumble and mixture preparation for improved efficiency, smoother idle, lower emissions and more power.
Magnetron® Electronic Ignition
Quick dependable starts with no maintenance required
Five-Inch Centrifugal Multi-Stage Air Cleaner
Provides maximum engine protection, especially under dirty and dusty conditions.
V-Twin OHV Technology
Superior balance, low vibration, lower emissions, improved valve life, better fuel economy and higher HP/Weight.
Industrial Grade Solenoid Shift Starter
Quick reliable starts.
Oil Cooler
Reduces oil temperature, improves lubrication and extends oil change intervals.
Centrally Located Oil Pump and Pickup
Faster priming and allows for a higher angle of operation.
Dynamically Balanced Crankshaft
Minimizes engine noise and vibration
Advanced Debris Management
Keeps engine clean and cool for enhanced durability and performance.
Dura-Bore Cast Iron Cylinder Sleeve
Withstands wear while providing improved oil control
Mechanical Compression Release
Smooth easy starting, longer starter life and provides an instant return to maximum power
Full Pressure Lubrication with Spin-On Oil Filter
Cleans oil and protects engine components to ensure maximum lubrication and long life.

SPECS

Model Number
613477
Engine Type
OHV (Overhead Valve)
HP (gross)*
35.0
Engine Displacement (cc)
993
Cylinder
Cast Iron Sleeve
Bore (mm)
86.0
Number of Cylinders
V-Twin
Oil Capacity (L)
2.3 with Filter
Compression Ratio
8.2
Air Cleaner
Heavy Duty Five-Inch Cyclonic Air Cleaner
Ignition System
Magnetron® Electronic Ignition
Lubrication System
Full Pressure Lubrication System with Oil Cleaner
Weight (kg)
56.8
Length (mm)
379
Width (mm)
496
Height (mm)
725
Muffler Included
No
Limited Commercial Warranty †
3 Years

TECHNICAL DOCUMENTS

Operator's Manual
Illustrated Parts List
