ISX™ 800

ISX™ 800

US Flag Manufactured in United States
Regular price$19,299.00
/
Commercial power. Commercial quality. The ISX™ 800 is engineered to increase efficiency and operator comfort. Combining next-generation Ferris®  ForeFront™ Suspension Technology with a 2-belt, 52" iCD™ Cutting System, means smoother rides and top-notch finishes.
TOP FEATURES
  • Briggs & Stratton® Commercial Series - EFI ETC
  • 52" iCD™ Cutting System
  • ForeFront™ Suspension System Technology

FEATURES

NEXT GENERATION FERRIS SUSPENSION TECHNOLOGY

Engine
Powered by a Briggs & Stratton® Commercial Series - EFI ETC for ultimate reliability
ForeFront™ Suspension System
Utilises four upper and lower control rods that ensure front caster bearings remain vertical through the full range of travel. For a smoother ride, more precise tracing of the terrain and an improved cut
EFI-ETC Technology
Briggs & Stratton Commercial Series EFI-ETC technology for easy starting and smooth performance
Integrated transmission
Commercial Hydro-Gear® ZT-3400™ transaxles, with 7" cooling fans designed for high performance and are fully serviceable
Operator convenience
Ergonomic riding mower control panel features cup-holder and fuel gauge
Easy access
Quick removal of the floor pan provides convenient access to the top of the deck for easy cleaning and service
iCD™ Cutting System
Engineered to produce the best possible cut in a multitude of conditions. Every component works together to achieve superior cut quality and longer component life
Spindles
Cast-aluminium greaseable spindles feature 1” shaft with 2.5” x 1” dual ball bearings with top access grease fittings and pressure relief valve
Rear bumper
Heavy-duty bumper protects the engine while also allowing for easy service access.
Exceptional performance
The well-tuned steering system delivers smooth and confident operation for excellent performance time after time

SPECS

Model
5902020
Engine
Briggs & Stratton® Commercial Series - EFI ETC
Engine Power Rating (HP) *
27
Displacement (cc)
810
PTO
Electric
Cylinders
2
Starter
Electric
Fuel Tank Capacity (L)
20.8
Cutting Width in(cm)
52 (132)
Cutting Height in(cm)
1.5 - 5 (38 - 127)
Spindles
Aluminium Greaseable
Deck Construction
iCD™ Cutting System, 2-belt
Suspension
ForeFront™ Suspension System - Front independent with four cast-iron control rods paired with medium size adjustable coil-over shocks and a rear swing-arm with large adjustable coil-over shocks
Transmission
Dual commercial Hydro-Gear® ZT-3400® transaxles with 7" cooling fans
Drive Axles (in)
1.125
Caster Tyres (in)
13 x 6.5 - 6
Drive Tyres (in)
23 x 10.5 - 12
Ground Speed-Fwd (kph)
0 - 16.1
Ground Speed-Rev (kph)
0 - 8.1
Overall Length (mm)
2058
Overall Width (mm) Deflector Down / Up
1651 / 1448
Dry Weight (kg)
508
Seat Package
Premium mid back adjustable suspension seat with armrests
Instrumentation
Dual-function hour meter, fuel level gauge in tank
ROPS
180° foldable
Controls / Safety Group
Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit/adjustable twin steering controls
Parking Brake / Safety Circuit
Hand operated internal transaxle brake
Warranty (Engine) †
3-Year limited manufacturer's warranty
Warranty (Balance of Machine) †
4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Coverage on other components varies, please see operator’s manual for complete details.
